Android 相对布局 RelativeLayout
2016-04-10 13:03
471 查看
android 相对布局RelativeLayout
中间用到了
<pre name="code" class="html"><RelativeLayout xmlns:android="http://schemas.android.com/apk/res/android" xmlns:tools="http://schemas.android.com/tools" android:layout_width="match_parent" android:layout_height="match_parent" tools:context="com.example.linearlayouttest.MainActivity" > <Button android:id="@+id/button1" android:layout_width="wrap_content" android:layout_height="wrap_content" android:layout_centerInParent="true" android:text="@string/bn1" /> <Button android:id="@+id/button2" android:layout_width="wrap_content" android:layout_height="wrap_content" android:layout_above="@id/button1" android:layout_alignStart="@id/button1" android:text="@string/bn2" /> <Button android:id="@+id/button3" android:layout_width="wrap_content" android:layout_height="wrap_content" android:layout_toStartOf="@id/button1" android:layout_alignBaseline="@id/button1" android:text="@string/bn3" /> <Button android:id="@+id/button4" android:layout_width="wrap_content" android:layout_height="wrap_content" android:layout_below="@id/button1" android:layout_alignStart="@id/button1" android:text="@string/bn4" /> <Button android:id="@+id/button5" android:layout_width="wrap_content" android:layout_height="wrap_content" android:layout_toEndOf="@id/button1" android:layout_alignBaseline="@id/button1" android:text="@string/bn5" /> </RelativeLayout>
中间用到了
android:layout_toStartOf="@id/button1" 和 android:layout_toEndOf="@id/button1"
相当于 layout_toLeftOf 和 layout_toRightOf
